Deluxe Drinking Water System

by American Plumber


Deluxe Drinking Water System with Quick Change Filter
#DW-600 by American Plumber

This easy-to-install system, with its quick change cartridge feature, makes water filtration as simple as it is necessary.

American Plumber deluxe drinking water system
Features:
  • Fresh, clean drinking water with a touch of a lever
  • Reduces lead, Lindane, Atrazine, chlorine taste & odor, and sediment, providing better tasting water
  • Compact undercounter filter with reliable chrome brass filter faucet
  • Single, 1/4 turn, quick-change cartridge prevents spills
  • NSF/ANSI Standard 53 certified to reduce Cryptosporidium and Giardia cysts by mechanical means
  • 0.5 micron (one millionth of a meter) filtration rating
  • Easy to install using copper, plastic, or flexible tubing
  • Environmentally friendly, disposable, 500 gallon life filter
  • Operating pressure range: 30 - 125 psi
  • Operating temperature range: 40 - 100°F.
  • Dimensions: 3" x 3" x 13-1/2"
  • Includes installation hardware

Description Price & Quantity
#DW-600 Deluxe Drinking Water System $86.14 Enter a quantity and
#600R Replacement Filter Cartridge - 0.5 micron $34.50 Enter a quantity and

DW-600 Drinking Water System Components

American Plumber DW-600 drinking water filter system componants

Easy To Install

  • Step 1: Turn off the water supply stop valve
  • Step 2: Install water supply adapter (included) to angle stop outlet (fits 1/2" slip joint outlets) - Note: If supply stop outlet is 3/8" compression outlet then you can use an Angle Stop Adapter Valve or Quick Tee Adapter sold below
  • Step 3: Attach mounting bracket undersink or inside cabinet
  • Step 4: Insert cartridge into mouting bracket with 1/4 turn twist to lock into place
  • Step 5: Install faucet into sink or top of countertop as desired
  • Step 6: Push insert a piece of tubing into the water supply adapter. On the other end of the tubing insert one of the plastic inserts into the tubing. Slide one of the chrome compression nuts over the tubing. Then slide one of the plastic sleeves over the tubing and thread onto the inlet of the water filter located at the top of the filter mounting bracket
  • Step 7: Using the other two chrome compression nuts, plastic inserts and plastic sleeves, (as described in Step 6) connect another piece of tubing into the outlet side of the filter (top of the mouting bracket) and the other end into the inlet of the filter faucet
  • Step 8: Turn on the water supply valve and check for leaks
  • Enjoy your fresh clean drinking water

Optional Alternative Installation Parts

Image Description Price & Quantity
image of angle stop adapter valve Angle Stop Adapter Valve
Inline inlet: 3/8" Female compression thread
Inline outlet: 3/8" Male comprssion thread
Valve outlet: 1/4" quick connect
$15.02 Enter a quantity and
image of quick tee add-a-line adapter Quick Tee Adapter
Inline inlet: 3/8" Female compression thread
Inline outlet: 3/8" Male comprssion thread
Tee side outlet: 1/4" Male compression thread
$7.86 Enter a quantity and

Easy To Change Cartridge

  • To change cartridge simply turn arrow from locked to unlocked position
  • Remove and discard
  • Insert cartridge and turn to locked position
  • Turn on water and enjoy
